Technische Daten
-
Technical data
- Données techniques
Bestell-Nummer
Order number
Numéro de commande
Diametre
A B C K L M N O
R
∆
Stahl
Steel
Acier
Aluminium
125
64 25 35
7,94
58 13 9 12,7 15
32
401.060.800 401.060.900
160
78 25 40
7,94
70 13 9 12,7 20
38,1
401.175.800 401.175.900
Amestra
Röhm
78 25 40
7,94
70 17 11 12,7 20
38,1
401.061.800 401.061.900
78 25 60
7,94
70 13 9 12,7 20
38,1
401.175.810 401.175.910
Amestra
Röhm
78 25 60
7,94
70 17 11 12,7 20
38,1
401.061.810 401.061.910
200
98 30 50
7,94
90 13 9 12,7 27
44,4
401.177.800 401.177.900
Amestra
Röhm
98 30 50
7,94
90 17 11 12,7 27
44,4
401.062.800 401.062.900
98 30 70
7,94
90 13 9 12,7 27
44,4
401.177.810 401.177.910
Amestra
Röhm
98 30 70
7,94
90 17 11 12,7 27
44,4
401.062.810 401.062.910
250
124 35 50
12,7
114 20 13 19,02 27
54
401.063.800 401.063.900
124 35 70
12,7
114 20 13 19,02 27
54
401.063.810 401.063.910
315
148 40 60
12,7
128 20 13 19,02 29
63,5
401.064.800 401.064.900
148 40 80
12,7
128 20 13 19,02 29
63,5
401.064.810 401.064.910
400
198 40 70
12,7
178 25 17 19,02 36
76,2
401.065.800 401.065.900
198 40 90
12,7
178 25 17 19,02 36
76,2
401.065.810 401.065.910
Technische Daten
-
Technical data
- Données techniques
Bestell-Nummer
Order number
Numéro de commande
Diametre
A B C K L M N O
R
∆
P
1,587mm
1,50mm
Stahl
Steel
Acier
Aluminium
160
78 40 40
70
1/16"x90°
472.160.840 472.160.940
78 40 60
70
1/16"x90°
472.160.860 472.160.960
78 40 40
70
1,5x60°
478.160.840 478.160.940
78 40 60
70
1,5x60°
478.160.860 478.160.960
200
98 40 50
90
1/16"x90°
472.200.850 472.200.950
98 40 70
90
1/16"x90°
472.200.870 472.200.970
98 40 50
90
1,5x60°
478.200.850 478.200.950
98 40 70
90
1,5x60°
478.200.870 478.200.970
250
124 50 50
114
1/16"x90°
472.250.850 472.250.950
124 50 70
114
1/16"x90°
472.250.870 472.250.970
124 50 50
114
1,5x60°
478.250.850 478.250.950
124 50 70
114
1,5x60°
478.250.870 478.250.970
315
148 50 60
128
1/16"x90°
472.315.860 472.315.960
148 50 80
128
1/16"x90°
472.315.880 472.315.980
148 50 60
128
1,5x60°
478.315.860 478.315.960
148 50 80
128
1,5x60°
478.315.880 478.315.980
400
198 60 70
178
1/16"x90°
472.400.870 472.400.970
198 60 90
178
1/16"x90°
472.400.890 472.400.990
198 60 70
178
1,5x60°
478.400.870 478.400.970
198 60 90
178
1,5x60°
478.400.890 478.400.990
SEGMENTBACKEN spitzverzahnt
WRAP AROUND JAWS serrated
MORS ENVELOPPANTS striés
Bestellbeispiel /
Type of order /
Exemple de commande
401.060.800:
K
7,92
N
9
R
20
∆
38,1
SEGMENTBACKEN ISO
WRAP AROUND JAWS ISO
MORS ENVELOPPANTS ISO
