Technische Daten
-
Technical data
- Données techniques
Bestell-Nummer
Order number
Numéro de
commande
Diametre
A B C K M N R ∆
P
1,50mm
3,00mm
110
48
25
25
8
11 6,5
8 15
M6
1,5x60°
478.086.000 478.086.001
110
54
25
30
10
14 9
8 14
M8
1,5x60°
478.108.000 478.108.001
135
60
25
30
10
14 9
8 19
M8
1,5x60°
478.108.500 478.108.501
168
77
35
35
11
14 9
17 20
M8
1,5x60°
478.118.600 478.118.601
77
30
60
11
14 9
17 20
M8
1,5x60°
478.118.660 478.118.661
165
72
30
40
12
17 11
15 20
M10
1,5x60°
478.120.000 478.120.001
72
30
60
12
17 11
15 20
M10
1,5x60°
478.120.060 478.120.061
210
100
34
44
14
19 13
20 25
M12
1,5x60°
478.142.000 478.142.001
90
34
60
14
19 13
20 25
M12
1,5x60°
478.142.060 478.142.061
90
34
80
14
19 13
20 25
M12
1,5x60°
478.142.080 478.142.081
254
110
40
48
16
19 13
20 30
M12
1,5x60°
478.162.500 478.162.501
110
40
60
16
19 13
25 30
M12
1,5x60°
478.162.560 478.162.561
110
40
80
16
19 13
25 30
M12
1,5x60°
478.162.580 478.162.581
304
130
50
50
18
22 15
30 30
M14
1,5x60°
478.184.000 478.184.001
130
50
80
18
22 15
30 30
M14
1,5x60°
478.184.080 478.184.081
304
130
50
50
21
25 17
30 30
M16
1,5x60°
478.216.000 478.216.001
381
160
60
80
22
32 21
37 43
M20
1,5x60°
478.220.000 478.220.001
530
195
65
68
25
32 21
50 60
M20
3x60°
479.250.000 479.250.001
610
210
75
98
25
32 21
60 60
M20
3x60°
479.250.500 479.250.501
Technische Daten
-
Technical data
- Données techniques
Bestell-Nummer
Order number
Numéro de
commande
Diametre
A B C K M N R ∆
P
1,50mm
3,00mm
110
54
25
30
10
14 9
8 14
M8
1,5x60°
478.108.000 478.108.001
135
60
25
30
10
14 9
8 19
M8
1,5x60°
478.108.500 478.108.501
110/135
50
25
30
11
14 9
8 16
M8
1,5x60°
478.118.000 478.118.001
135
60
25
30
11
14 9
8 19
M8
1,5x60°
478.118.500 478.118.501
165
72
30
40
12
17 11
15 20
M10
1,5x60°
478.120.000 478.120.001
72
30
60
12
17 11
15 20
M10
1,5x60°
478.120.060 478.120.061
200/210
100
34
44
14
19 13
20 25
M12
1,5x60°
478.142.000 478.142.001
90
34
60
14
19 13
20 25
M12
1,5x60°
478.142.060 478.142.061
90
34
80
14
19 13
20 25
M12
1,5x60°
478.142.080 478.142.081
210/254
110
40
50
16
19 13
20 25
M12
1,5x60°
478.162.000 478.162.001
110
40
60
16
19 13
20 25
M12
1,5x60°
478.162.060 478.162.061
110
40
80
16
19 13
20 25
M12
1,5x60°
478.162.080 478.162.081
254/304
130
50
50
18
22 15
30 30
M14
1,5x60°
478.184.000 478.184.001
130
50
80
18
22 15
30 30
M14
1,5x60°
478.184.080 478.184.081
304
110
50
80
21
25 17
25 35
M16
1,5x60°
478.216.500 478.216.501
254
110
45
45
16
19 13
20 30
M12
3x60°
479.162.000 479.162.001
304
130
50
50
18
22 15
30 30
M14
3x60°
479.184.000 479.184.001
381
126
50
58
21
25 17
26 40
M16
3x60°
479.216.000 479.216.001
381/610
156
65
68
26
32 21
34 50
M20
3x60°
479.260.500 479.260.501
KITAGAWA
MATSUMOTO
HOWA
3
3
3
3
WEICHE AUFSATZBACKEN SPITZVERZAHNT
SERRATED SOFT TOP JAWS
MORS DOUX RAPPORTES STRIES
