Technische Daten
-
Technical data
- Données techniques
Bestell-Nummer
Order number
Numéro de
commande
Diametre
A B C K M N R ∆
P
1,587mm
2,38mm
160
70
40
40
17
19 13
15 22
M12
1/16"x90°
472.172.200 472.172.201
70
40
60
17
19 13
15 22
M12
1/16"x90°
472.172.260 472.172.261
200
90
40
40
17
19 13
20 23
M12
1/16"x90°
472.172.000 472.172.001
90
40
60
17
19 13
20 23
M12
1/16"x90°
472.172.060 472.172.061
90
40
80
17
19 13
20 23
M12
1/16"x90°
472.172.080 472.172.081
250/315
95
50
58
21
25 17
15 30
M16
1/16"x90°
472.216.500 472.216.501
120
50
50
21
25 17
30 30
M16
1/16"x90°
472.216.050 472.216.051
120
50
80
21
25 17
30 30
M16
1/16"x90°
472.216.080 472.216.081
300/400
120
60
60
25,5
32 21
22 35
M20
1/16"x90°
472.250.000 472.250.001
140
60
90
25,5
32 21
30 35
M20
1/16"x90°
472.250.090 472.250.091
400/630
155
60
60
25,5
32 21
30 35
M20
3/32"x90°
473.250.000 473.250.001
155
60
100
25,5
32 21
30 35
M20
3/32"x90°
473.250.100 473.250.101
Technische Daten
-
Technical data
- Données techniques
Bestell-Nummer
Order number
Numéro de
commande
Diametre
A B C K M N R ∆
P
1,587mm
2,38mm
125/150
60
30
40
12
14 9
15 16
M8
1/16"x90°
472.128.000 472.128.001
165/170
70
35
35
14
17 11
16 16
M10
1/16"x90°
472.140.000 472.140.001
70
40
60
14
17 11
16 16
M10
1/16"x90°
472.140.060 472.140.061
200/210
90
40
40
17
19 13
20 23
M12
1/16"x90°
472.172.000 472.172.001
90
40
60
17
19 13
20 23
M12
1/16"x90°
472.172.060 472.172.061
90
40
80
17
19 13
20 23
M12
1/16"x90°
472.172.080 472.172.081
200/250
110
45
45
21
25 17
20 30
M16
1/16"x90°
472.216.000 472.216.001
305/315
120
50
50
21
25 17
30 30
M16
1/16"x90°
472.216.050 472.216.051
120
50
80
21
25 17
30 30
M16
1/16"x90°
472.216.080 472.216.081
400
140
60
60
21
25 17
25 30
M16
1/16"x90°
472.216.600 472.216.601
250/315
120
60
60
25,5
32 21
22 35
M20
1/16"x90°
472.250.000 472.250.001
140
60
90
25,5
32 21
30 35
M20
1/16"x90°
472.250.090 472.250.091
400/630
155
60
60
25,5
32 21
30 35
M20
3/32"x90°
473.250.000 473.250.001
155
60
100
25,5
32 21
30 35
M20
3/32"x90°
473.250.100 473.250.101
500/800
160
70
75
28
32 21
25 38
M20
3/32"x90°
473.280.080 473.280.081
170
60
60
28
32 21
27 35
M20
3/32"x90°
473.280.060 473.280.061
AUTOBLOK
FORKARDT
3
3
3
3
WEICHE AUFSATZBACKEN SPITZVERZAHNT
SERRATED SOFT TOP JAWS
MORS DOUX RAPPORTES STRIES
